The Danish Lymphoid Cancer Research (DALY-CARE) Data Resource: The Basis for Developing Data-Driven Hematology

Introduction

Lymphoma, chronic lymphocytic leukemia (CLL), plasma cell dyscrasia (PCD) and their precursors are a highly heterogenous group of hematological malignancies in the blood, bone marrow and/or lymphoid tissues.¹ They span from precursor states such as monoclonal B-cell lymphocytosis (MBL) and monoclonal gammopathy of uncertain significance (MGUS), over indolent B-cell lymphomas (BCL), smoldering multiple myeloma (MM) and CLL, to aggressive high-grade BCL and PCD such as amyloid light-chain amyloidosis. Lymphoid-lineage cancers (LC) account for approximately 5% of all newly diagnosed cancers and more than 4% of all cancer deaths worldwide, whereas precursors such as MGUS and MBL may be identified in 5% to 12% of healthy, older individuals.^2,3

Despite the pathological, molecular, and clinical heterogeneity of LC, they share several common features. First, all LC derive from or are directly caused by clonal lymphoid-lineage expansion in blood, bone marrow and/or lymphoid tissues. Second, they are diagnosed by histological tissue staining, flow cytometry, and/or molecular analyses, and the diagnostic workup typically includes biochemical blood tests, a bone marrow examination, and computer tomography (CT) or positron emission tomography (PET)/CT imaging. Third, LC share common epidemiology such as older age at diagnosis and male predominance, whereas socioeconomic status and lifestyle exposures are typically not well-correlated with LC. Fourth, LC develops due to dysregulation of immune function, stimulation and signaling in conjunction with acquisition of driver mutations.⁴ Lastly, patients with LC precursor states, CLL, indolent lymphoma or smoldering MM do not benefit from pre-emptive treatment and are therefore often followed by a watch-and-wait strategy. If or when treatment is required, it usually includes corticosteroids, chemotherapy, and immunotherapy in combination, while targeted therapies in recent years are replacing or added to chemoimmunotherapy.⁵ From an epidemiological, molecular, and data-driven perspective, the commonalities between LC offer a unique opportunity for identifying common features, which may facilitate modelling disease outcomes using meta-learning and federated learning. Achieving state-of-the-art accuracy of predictive models will require the joint modelling of diseases, ie including training data from patients with lymphoma and multiple myeloma may most likely improve the predictive accuracy for patients with CLL.⁶

The main driver in the recent successes of AI for image analysis and natural language processing outside of medicine is the critical mass of researchers working on the same benchmarks competitively and collaboratively. This ensures a continuous improvement of state-of-the-art performance on the given datasets.⁷ By contrast, access to most medical data is heavily restricted. For instance, the performance of prognostic models in CLL has plateaued over the last 20 years likely due to lack of (1) multiple data modalities, (2) time-series modelling, and (3) a diverse set of researchers with access to the same benchmarks.⁶ In turn, most mAI is developed on outcomes that are easily and publicly accessible, but not necessarily clinically useful in broader clinical setting (eg the MIMIC III and IV datasets).^6,8

We therefore aim to address the aforementioned issues with lack of multimodality, common access, and clinically valid outcomes, and provide an overview of the DALY-CARE data resource, its infrastructure, and data formats.

Ethical Approvements

The DALY-CARE protocol has been approved by the Danish Health Data Authority and National Ethics Committee (approvals P-2020-561 and 1804410, respectively). Specifically, DALY-CARE is approved for collection of 1) biobank samples and 2) electronic health data (EHD) retrospectively and prospectively for all Danish adult residents diagnosed with LC in order to study the integrated clinicopathological profile of LC based on medical history, clinical and paraclinical (ie biochemical, cellular, microbiological, pathological, radiology, molecular, and genetic) routine data, while molecular omics (eg chip-array techniques, genomics, transcriptomics, proteomics, and microbiomics) and functional analyses (eg immune assays, phospho-flow cytometry, in vitro drug screening and mouse xenograft models) of adjoined biobank samples are covered by the protocol for correlations with the course of treatment and clinical outcome based on clinical epidemiology and data-driven mAI approaches.

Data Sources

The DALY-CARE data resource is a collection of EHD primarily gathered from existing data sources as summarized in Table 1. From the Danish Clinical Quality Program – National Clinical Registries (RKKP) registers, these include the Danish National Lymphoma Registry (LYFO)⁹ since 2005, the Danish National Multiple Myeloma Database (DaMyDa)¹⁰ since 2005, and the Danish National Chronic Lymphocytic Leukemia Registry (DCLLR)¹¹ since 2008. Exhaustive lists of variables in the RKKP registers are described elsewhere.¹² From the Danish Health Data Authority (SDS) since 2002, existing data sources included the Register of Pharmaceutical Sales covering prescription drug data (LSR),¹³ the National Hospital Medication Register covering in-hospital medication (SMR, coverage since 2004),¹⁴ the Danish National Pathology Register (PATOBANK) including pathology notes (free text) and SNOMED codes,¹⁵ the Clinical Laboratory Information System Database with routine laboratory results (LABKA),¹⁶ the Danish Register of Causes of Death (DAR),¹⁷ the Danish National Patient Registry (LPR) versions 1 and 3,^18,19 and the Danish Cancer Registry (DCR).²⁰

Table 1 Data sources in DALY-CARE

We further retrieved EHD from 16 modules in the EPIC^®-based EHR system in eastern Denmark (Sundhedsplatformen [SP]) including 1) administered medicine, 2) admissions (ADT), 3) active in-hospital diagnoses, 4) all test results, 5) hematology/oncology treatment plans, 6) microbiology charts, 7) transfers between departments, 8) intensive care unit admissions, 9) medical notes (as free text), 10) prescribed medicine, 11) out- and in-patient visits and diagnoses, 12) anthropometrics, 13) a social history of smoking and alcohol consumption, and 14) vital signs, 15) do-not-resuscitate (DNR) orders, and 16) medical imaging (Supplementary Table S1 and Supplementary Material).

Additionally, we gathered EHD indirectly from laboratory systems at our institution. These included cleaned versions of the Danish Microbiology Database (MiBa)²¹ and LABKA retrieved through the Personalised Medicine of Infectious Complication in Immune Deficiency (PERSIMUNE) covering the Capital Region of Denmark (Table 1).²² In addition, we added summary reports and results directly from the laboratory systems for routine flow cytometry analyses,²³ immunoglobulin heavy-chain variable gene (IGHV) analyses including stereotypic subset designation,²⁴ targeted next-generation sequencing (tNGS),²⁵ and fluorescence in situ hybridization (FISH) reports. Manually curated datasets collected through EHR reviews include information on patients receiving second-line CLL treatment, patients with CLL treated with ibrutinib, patients with MM treated with daratumumab, and patients with CLL developing Richter’s transformation from previously published cohorts.^26–29

Finally, the DALY-CARE protocol specifically allows for functional and molecular analyses including omics of biobank samples from individuals in the cohort. For this purpose, we gathered available biobank information from four large Danish biobanks, namely the CLL biobank, the Copenhagen Hospital Biobank, the Danish Cancer Biobank, and PERSIMUNE biobank (Table 1).³⁰ Imputed genotypes from peripheral blood at time of first hospital blood-workup are availble in more than 11,000 patients (Supplementary Material).³¹

Main Variables

Variables in existing data sources have been described elsewhere (Supplementary Table S2).^{9–11,13–17,19,21} In short, baseline demographic and prognostic information (eg clinical stage, biochemical, and molecular data), as well as information on treatment, response, and survival are assembled from the RKKP registers. The main variables use the Danish Medical Classification System (SKS) encoding³² that, in short, covers diagnoses (D-SKS or ICD10 codes), medicine (M-SKS codes or anatomical therapeutic chemical [ATC]), surgical (K-SKS codes), radiological (UX SKS codes) and treatment procedures (B-SKS codes) including specific antineoplastic, immunotherapy, and radiotherapy codes (ie BWH, BOJH1, and BWGC SKS codes, respectively).¹⁹ Further, the biochemical data use nomenclature property units (NPU) codes, health care providers use SHAK codes, and pathology data use SNOMED codes and free-text notes (Supplementary Material). These codes facilitate clear definitions and easy mapping across different datasets (Supplementary Tables S3 and S4). All diagnoses, medicine, biochemistry, and procedures across all available datasets have been gathered into independent aggregated tables. Data do not include sensitive information on ethnicity, religion, or socio-economic status.

Database Infrastructure

The DALY-CARE data resource is based on open source scalable PostgreSQL located inside a secure ISO 27001 certified private cloud on a high-performance supercomputer at the Danish National Genome Center (NGC) research infrastructure. The server is accessed via a Federal Information Processing Standard (FIPS) complaint virtual desktop interface (VDI) that provides full separation between users. Built specifically with data security and privacy in mind, the platform uses 2-factor authentication (2FA) and layered security approach. The platform is on-premises and does not use any components that are hosted outside the infrastructure, which ensures data security and compliance with the statutory acts.³³

All data are pseudonymized based on a single patient ID linked to the Danish Civil Registration System.³⁴ This allows for unique identification of all patients and enables easy data linkage across all datasets while protecting individual patients’ data privacy (Figure 1a). All raw data are available directly in the DALY-CARE database. Newly retrieved data are quality assessed, and previous data cuts are logged to ensure the reproducibility of all studies. All RKKP, SDS, and EHR data are updated once yearly, and EHR data may be updated upon request.

Figure 1 Schematic overview of the Danish Lymphoid Cancer Research (DALY-CARE) data resource. Data from various sources including Danish nationwide registers, hematological quality registers, electronic health record data, and hematological laboratories may be linked using a single pseudonymized patient ID (a). Hosted on the Danish National Genome Center high-performance computer (HPC) cloud, all data are placed in a PostgreSQL database accessed by 2-factor authentication (2FA) and loaded via R or Python software (b). Database queries and pipelines to load and transform data based on encoded data (eg patient ID, international classification of disease version 10 [ICD10], nomenclature property units [NPU], and anatomical therapeutic chemical [ATC]) facilitate easy data transformation commonly used for survival analyses and data-driven research (c).

The DALY-CARE server is divided into two databases with three schemas each:

1. import
   1. public contains raw data retrieved from RKKP, SDS, EHR, and PERSIMUNE.
   2. laboratory contains data from hematological laboratories including flow cytometry, FISH, IGHV, and NGS data.
   3. lookup_tables contain tables to map encoded data including SNOMED, SKS, ATC, ICD10, NPU, and SHAK.
2. core
   1. public contains cleaned versions of raw datasets and aggregated data from multiple data sources.
   2. curated contains manually curated datasets obtained from manual EHR reviews and NGS data.
   3. lookup_tables contain cleaned tables to map standard coding.

We created data processing pipelines and functions for loading and processing the data in both R and Python software (Figure 1b and Supplementary Material). This includes pipelines that transform the raw data into a format ready to use by predictive models (feature generation) and scripts that define and extract clinical outcomes from the raw datasets. We grouped functions based on their specific purpose inside or general use outside the DALY-CARE server to allow for synergy in larger collaboratives of Danish epidemiologists and data scientists studying similar register data as well as for adaptation to similar international data. Importantly, the pipelines in R and Python software allow for direct database queries to quickly load data using indexed variables (Supplementary Table S3).^35,36

Study Population

We included all Danish adult residents registered with an LC diagnosis in 1) the RKKP registers, 2) the SDS registers, and 3) EHR data since 1 January 2002 using International Classification of Diseases version 10 (ICD10; ie C81.x-C90.x, C91.1-C91.9, C95.1, C95.7, C95.9, D47.2, D47.9B, and E85.8A) and Systematized Nomenclature of Medicine (SNOMED) codes, which could be mapped to ICD10 codes for LCs (Supplementary Table S5).³⁷ The nationwide coverage for malignant LC diagnoses within RKKP has previously been estimated to 99%.^10,11,38 The cutoff date for inclusion of data was 15 Nov 2023.

In total, we included 65,744 individuals with an LC of whom 35,399 (53.8%) had more than one LC diagnosis: 15,838 (24.1%), 10,420 (15.8%), 5315 (8.1%), and 3826 (5.8%) patients had 2, 3, 4, and >4 different LC diagnoses, respectively (Supplementary Figure S1). Most patients with multiple LC diagnoses were initially diagnosed with unspecified LC (eg C81.9, C82.9, C85.5, C85.9, and C91.9) followed by specified subclassification, whereas fewer patients had multiple diseases, progressed from precursor states to overt LC or transformed to more aggressive disease (Figure 2). The 20 most common LC diagnoses could be attributed to 62,946 patients (95.7%) and are summarized in Table 2. Please see an exhaustive list in Supplementary Table S6 and note that each patient may be registered with multiple LC diagnoses.

Table 2 Common DALY-CARE diagnoses

Figure 2 Correlations between lymphoid-lineage cancer (LC) ICD10 diagnoses shown as pairwise Fisher’s exact tests. The log odds ratio is indicated when the false detection rate (FDR) was above 0.1. ICD10 pairs with an FDR ≥0.1 are indicated in white. Abbreviations: BCL, B-cell lymphoma; CLL, chronic lymphocytic leukemia; DLBCL, diffuse large B-cell lymphoma; EMZL, extranodal marginal zone lymphoma; FL, follicular lymphoma; HL, Hodgkin lymphoma; LL, lymphoid leukemia; LPL, lymphoplasmacytic lymphoma; MCL, mantle cell lymphoma; MGUS, monoclonal gammopathy of uncertain significance; MM, multiple myeloma; MBL, monoclonal B-cell lymphocytosis; NHL, non-Hodgkin lymphoma; ns, nodular sclerosis; NOS, not otherwise specified; SLL, small lymphocytic lymphoma; UNS, unspecified; WM, Waldenström macroglobulinemia.

At time of first LC diagnosis for patients with common LC entities (Supplementary Table S7), the median age was 70.3 years (interquartile range [IQR] 60.7;77.9) and 56.1% were male (Table 3). A detailed description of the patients and baseline characteristics is available in the Supplementary Material. We further calculated baseline polypharmacy defined as <5 vs ≥5 prescriptions in the year prior to first LC diagnosis, Charlson comorbidity index (CCI) scores (Supplementary Table S8), and disease-specific international prognostic indices (Supplementary Table S9).^39,40 From the cause of death register, the RKKP registers, and EHR data, we compiled dates of last follow-up or death and calculated time from first LC diagnosis to death or end of follow-up. As a result, survival data are readily available (Supplementary Figures S2 and S3). We underscore that by including LC diagnosis codes from in-patient registers (ie LPR and EHR), the observed number of patients will represent the combination of incident and prevalent cases.

Table 3 Patient characteristics

Biobank Material

On top of the register and EHR data, we also included laboratory data as indicated in Table 1. To facilitate large-scale omic studies in DALY-CARE, we searched four large Danish biobanks and identified 40,863 biobank samples either stored on different dates or collected from different tissues from 18,528 individuals.³⁰ This included 21,431 samples among 9636 patients with lymphoma (ICD10 codes C81.x-C89.x), 11,043 samples in 3809 patients with CLL (ICD10 code C91.1), and 6206 samples in 3216 patients with PCD (ICD10 codes C90.0-C90.3, D47.2, and E85.8A). To create a large genetic repository for future studies, genotyping (n>12,000), whole-genome sequencing (n>2000), and proteomics (n>800) is ongoing.

Disparities in Data and Coverage

To avoid bias when linking different datasets, we here provide an overview of coverage over time for data from RKKP, SDS, EHR, and PERSIMUNE datasets. Temporal coverage and number of unique patients for 45 datasets are provided in Supplementary Figures S4–S9. Generally, more recent data show better coverage than older data: 13 out of 54 data sources plotted date back to 2002, while all 54 data sources have data available for 2019 (Figure 3 and Supplementary Figure S4). While all data are population-based, data collection was centered around eastern Denmark and our institution in specific. We thus calculated the prevalence of CLL, lymphoma, and PCD disease categories in the data available in DALY-CARE to assess regional disparities, which would likely represent differences in data coverage (Figure 4). For instance, differences in regional coverage over time reveal better coverage in the Capital Region for biochemical data such as LABKA (Supplementary Figures S4–S8 panels F1 and H1).

Figure 3 Overview of temporal coverage in 12 key datasets in the DALY-CARE data resource. RKKP hematological quality registers are wide format datasets, where data are typically entered upon diagnosis/registration, upon treatment, relapse, and follow-up (a–c). SDS LPR register was replaced by LPR3 in Feb 2019 (d and g). Epikur (prescriptions), LABKA (blood tests), and PATOBANK (pathology requisitions) were independent of this update (e, f and h). We underscore that similar data from different data sources may have different time coverage (f and i). The electronic health record (EHR) system of eastern Denmark (SP) went live in Mar 2016 (j). Even so, medical notes antedating go-live dates from the previous EHR system were imported and are available as historic notes (k). A steadily increasing number of antimicrobial analyses was observed (l). Each panel shows the time coverage of a single dataset (a–l). Note that the y-axis shows the number of observations in three-month intervals on a log-scale. Lines above bins represent kernel density estimates of the counts. All 45 main datasets are detailed in Supplementary Figure S4.

Figure 4 Number of patients in each disease category per 100,000 residents for patients with chronic lymphocytic leukemia (CLL), lymphoma (LYMPH), and plasma cell dyscrasia (PCD). Numbers included all patients in the DALY-CARE data resource regardless of vital status. Please see definition of disease category in the Supplementary Material.

Previous DALY-CARE Usage

Due to the variety of data sources and data modalities, the DALY-CARE data resource may facilitate a diverse set of research projects. To provide an overview of the unique possibilities of DALY-CARE, we highlight examples of previously published work in Supplementary Table S10 including use of biobank data to find novel prognostic markers, investigation of real-world evidence of prognostic factors influencing the efficacy of health care, and development and deployment of mAI algorithms (Supplemental Material). Notably, we developed the data driven model CLL-TIM for predicting infection and/or CLL treatment in newly diagnosed CLL. This model was implemented into the ongoing PreVent-ACaLL clinical trial (NCT03868722) and deployed into the EHR system of eastern Denmark.⁴¹

Data Availability

According to Danish legislation, EHD may not be shared publicly. Within the approved protocol (available on Github), the data may be shared on a collaborative basis based on a data processing agreement (please see DPA template available on Github). All analyses must be performed on the DALY-CARE data resource at the NGC. Except for free-text tables (ie pathology, medical imaging, and medical notes), dummy tables and the underlying code for this study is publicly available on Github.

Improvements in patient care are intrinsically tied to the ability to access and share data easily.⁴² We here demonstrate how DALY-CARE allows researchers to identify complex patterns across different datasets, patient cohorts, and subgroups on a collaborative basis. By making the DALY-CARE data resource FAIR (findable, accessible, interoperable, and reusable), we provide the opportunity to share definitions, outcomes and ultimately data that will allow for competitive modeling on outcomes that likely increase the predictive performance of prognostic models. To translate these data-driven perspectives into benefits for patients on a national and international level, we believe it is crucial to break down the arbitrary distinction between primary and secondary use of EHD. Thus, utilizing daily routine EHR data and national registers for the purposes of clinical epidemiology, precision medicine and to enrich omic analyses with clinical data within the approved protocol.

Methodological Considerations

The DALY-CARE cohort is truly population-based as nearly all Danish adult LC patients are referred to one of eight hematological centers and cancer registration is mandatory by law. This results in a register coverage of 99%.³⁸ Even so, we found large regional disparities in the available data for patients, mainly owing to EHR data being available for only two out of five Danish Regions, covering half of the Danish population. The use of ICD10 codes upon admissions may also differ widely across institutions. This skew in availability and usage could limit the scope of the possible studies or produce unintentional biases in data driven algorithms if they are not accounted for. Like other EHD archives, data in DALY-CARE are affected by shifts in systems such as the transition from LPR to LPR3 (ie 2 Feb 2019) or implementation of EPIC^® in eastern Denmark (from May 2016 through Nov 2017; Supplementary Material). These time dependent changes in data and data formats are important to recognize to avoid biases that could lead data driven algorithms astray. To this end, we focused on 1) describing when and where the data are available, 2) standardization and quality control for measurements (ie making the same measures using different units commensurable), and 3) using robust clinical definitions to calculate features based on domain-knowledge such as prognostic indices.

By highlighting previously published work (Supplementary Table S10), we believe that the DALY-CARE data resource will serve as an important first step towards standardizing and creating similar data resources for other research groups. This would help alleviating the problem of limited training data by enabling the use of techniques that can leverage information learned from training on other cohorts, such as meta-learning,⁴³ and have so far helped to pool larger international cohorts for rare diseases and events.^44–49 Beyond the national generalization (eg SKS coding), we mapped 90% of our curated data from medicine, laboratory measurements and diagnoses to OMOP standardization to facilitate international collaborations. This will also serve as a critically important step for implementing state-of-the-art mAI that aggregate information across countries using federated learning.

With access to free-text medical notes for 22,708 patients within the DALY-CARE data resource, we have initiated work to test natural language processing for identification of specific events such as infections. Ongoing research in this field continues to show promise.^50,51 From our preliminary results, it is, however, unclear whether unstructured text data will be generalizable across different hospitals and diseases.⁵²

We recognize the lack of large, shared datasets as the biggest obstacle for development in mAI research and call for the integration and use of primary health care data in mAI research on a coordinated national level. By creating a secure research environment within the DALY-CARE data resource, we here deliver proof-of-concept to overcome this barrier, thus paving the way for expanding into different domains (outside hematology) for other institutions.

Medical interventions for LC patients are often implemented without scientific evidence, and many interventions will never be investigated in randomized clinical trials (RCT).⁵³ DALY-CARE provides means to qualify and inform the impact of changes in health care practice that have not, cannot, and likely will never be tested sufficiently in RCTs. This is exemplified by monitoring overall survival, health care utilizations and infections for patients ending specialized follow-up or receiving immunoglobulin replacement therapy.

Conclusion

The DALY-CARE data resource includes multimodal health data for more than 65,000 patients with LC, gathered and stored on a super-computer cloud ensuring data privacy, storing capacity, and the processing power needed without compromising the risk of data migration.⁵⁴ Based on published studies using the DALY-CARE data resource, we provide examples of how DALY-CARE can lead to (1) finding novel prognostic markers using biobank data, (2) using real-world evidence studies to evaluate the efficacy of routine health care, and (3) deploying mAI algorithms directly into EHR systems. Thus, DALY-CARE allows for development of near real-time decision-support tools and extrapolation of clinical trial results into clinical practice, thereby improving care for patients with LC and paving the way for truly data-driven hematology, while facilitating streamlining of health data infrastructure across cohorts and medical domains.
