Back to Browse Journals » International Journal of Nanomedicine » Volume 6

Nanostructured model implants for in vivo studies: influence of well-defined nanotopography on de novo bone formation on titanium implants

Authors Ballo A, Agheli H, Lausmaa J, Thomsen P, Petronis S

Published 20 December 2011 Volume 2011:6 Pages 3415—3428


Review by Single-blind

Peer reviewer comments 4

Ahmed Ballo1,3, Hossein Agheli2,3, Jukka Lausmaa4, Peter Thomsen1,3, Sarunas Petronis2,3
Department of Biomaterials, Sahlgrenska Academy, University of Gothenburg, Gothenburg, Sweden; 2Applied Physics, Chalmers University of Technology, Gothenburg, Sweden; 3BIOMATCELL, VINN Excellence Center of Biomaterials and Cell Therapy, Gothenburg, Sweden; 4Department of Chemistry and Materials Technology, SP Technical Research Institute of Sweden, Borås, Sweden

Abstract: An implantable model system was developed to investigate the effects of nanoscale surface properties on the osseointegration of titanium implants in rat tibia. Topographical nanostructures with a well-defined shape (semispherical protrusions) and variable size (60 nm, 120 nm and 220 nm) were produced by colloidal lithography on the machined implants. Furthermore, the implants were sputter-coated with titanium to ensure a uniform surface chemical composition. The histological evaluation of bone around the implants at 7 days and 28 days after implantation was performed on the ground sections using optical and scanning electron microscopy. Differences between groups were found mainly in the new bone formation process in the endosteal and marrow bone compartments after 28 days of implantation. Implant surfaces with 60 nm features demonstrated significantly higher bone-implant contact (BIC, 76%) compared with the 120 nm (45%) and control (57%) surfaces. This effect was correlated to the higher density and curvature of the 60 nm protrusions. Within the developed model system, nanoscale protrusions could be applied and systematically varied in size in the presence of microscale background roughness on complex screw-shaped implants. Moreover, the model can be adapted for the systematic variation of surface nanofeature density and chemistry, which opens up new possibilities for in vivo studies of various nanoscale surface-bone interactions.

Keywords: in vivo, nanotopography, osseointegration, titanium implant, colloidal lithography

Creative Commons License This work is published and licensed by Dove Medical Press Limited. The full terms of this license are available at and incorporate the Creative Commons Attribution - Non Commercial (unported, v3.0) License. By accessing the work you hereby accept the Terms. Non-commercial uses of the work are permitted without any further permission from Dove Medical Press Limited, provided the work is properly attributed. For permission for commercial use of this work, please see paragraphs 4.2 and 5 of our Terms.

Download Article [PDF] View Full Text [HTML]
